Enterprise Performance with Intelligent Network Management
The USCX1510P-16T2S network switch is a powerful Smart Web Managed Multi-Gigabit PoE+ Switch designed for businesses that need higher network performance, advanced traffic management, and reliable Power over Ethernet. Featuring sixteen 2.5 Gigabit Ethernet PoE+ ports, this compact switch delivers up to 2.5× the bandwidth of traditional Gigabit switches while providing enterprise-class Layer 2 management through an intuitive web interface.
With support for VLAN, QoS, Port Trunking, RSTP, ERPS, and other intelligent networking features, this network switch is the ideal solution for Wi-Fi 6/6E deployments, IP surveillance, VoIP systems, NAS storage, and growing business networks.
Future-Proof Your Business Network
This Ethernet switch combines 2.5 Gigabit Multi-Gigabit performance, enterprise-class Layer 2 management, and integrated PoE+ into one compact, cost-effective solution. Whether you're deploying Wi-Fi 6 access points, expanding an IP surveillance system, or upgrading your office infrastructure, this switch provides the speed, intelligence, and reliability needed for today's demanding network environments while preparing your business for tomorrow's bandwidth requirements.
Sixteen 2.5 Gigabit PoE+ Ports
- 16 × 100/1000/2500Base-T RJ45 ports
- Auto-negotiating 10/100/1000/2500 Mbps speeds
- IEEE 802.3af/at PoE+ compliant
- Up to 30W PoE output per port
- Auto MDI/MDIX support
One Ethernet cable provides both network connectivity and power, simplifying installation for powered network devices.
Smart Web Management
Take complete control of your network through an intuitive browser-based management interface.
- IEEE 802.1Q VLAN
- Quality of Service (QoS)
- Port Trunking (Link Aggregation)
- Port Monitoring
- Traffic Statistics
- Port Mirroring
- Network Diagnostics
- User Management
These advanced features allow administrators to optimize network performance, improve security, and simplify troubleshooting without requiring complex command-line configuration.
High Availability & Network Protection
This Ethernet switch is built for reliable business networking with advanced redundancy protocols.
- RSTP (Rapid Spanning Tree Protocol)for fast network convergence
- ERPS (Ethernet Ring Protection Switching) for rapid failover
- Loop prevention
- Broadcast storm protection
- Stable network operation during failures
These capabilities help minimize downtime and maintain uninterrupted connectivity for mission-critical applications.
Optimized for Modern Multi-Gig Networks
With the growing adoption of Wi-Fi 6, Wi-Fi 7, high-performance NAS systems, and multi-gigabit workstations, traditional 1 Gigabit switches can quickly become a bottleneck.
The 2.5 Gigabit interfaces provide significantly greater bandwidth while remaining compatible with existing Cat5e or better Ethernet cabling in many installations.
Ideal for:
- Wi-Fi 6 & Wi-Fi 6E Access Points
- Business NAS Servers
- 4K/8K Video Editing
- High-speed Workstations
- IP Surveillance Systems
- VoIP Networks
- Small Business Servers
Power over Ethernet Simplifies Installation
Integrated PoE+ technology reduces installation costs by delivering power and data through one Ethernet cable.
Perfect for powering:
- Wireless Access Points
- IP Security Cameras
- VoIP Phones
- Access Control Devices
- IoT Gateways
- Network Sensors
No separate power outlets are required near connected devices, making installations cleaner and more flexible.
| Technical Specifications |
| Model |
USCX1510P-16T2S |
| Switch Type |
Smart Web Managed Multi-Gigabit PoE+ Switch |
| PoE Standard |
IEEE 802.3af/at |
| PoE Ports |
16 × 100/1000/2500Base-T RJ45 |
| PoE Output |
Up to 30W per port |
| Management |
Web-based management |
| Layer 2 Features |
VLAN, QoS, Trunking, RSTP, ERPS |
| Housing |
Industrial Metal |
| Protection Rating |
IP40 |
| Cooling |
Fanless |
| Mounting |
Desktop |
| Operating Temperature |
-40°C to +85°C |
| Certifications |
CE, FCC, RoHS |
