High-Density Gigabit PoE Networking for Business
The X1500P-16T2S is a professional 16-port unmanaged Gigabit PoE Ethernet switch designed for small and medium-sized businesses, surveillance systems, hospitality, education, and enterprise networks. Featuring 16 Gigabit RJ45 PoE ports and 2 Gigabit SFP fiber uplink ports, it provides reliable high-speed connectivity while simplifying installation through Plug & Play operation. The switch supports IEEE 802.3af/at PoE standards and is built for dependable, maintenance-free network expansion.
Perfect for Growing Networks
X1500P-16T2S combines the simplicity of an unmanaged switch with enterprise-grade PoE performance and fiber uplink flexibility. Whether you're deploying a surveillance system, expanding a business network, or powering wireless access points, this switch provides dependable Gigabit connectivity, intelligent PoE power delivery, and future-ready fiber expansion in a cost-effective solution.
16 Gigabit PoE Ports
- 16 × 10/100/1000 Mbps RJ45 Ethernet ports
- Wire-speed Gigabit data transmission
- Automatic speed negotiation
- Auto MDI/MDIX on every port
Dual Gigabit SFP Fiber Uplinks
- 2 × 1000 Mbps SFP fiber uplink ports
- Long-distance fiber connectivity
- High-speed backbone connections
- Ideal for linking switches between buildings or network cabinets
Intelligent AI PoE+
- IEEE 802.3af/at compliant
- Delivers power and data over a single Ethernet cable
- Automatic powered device detection
- Intelligent power allocation and protection
Plug & Play Simplicity
- No software or configuration required
- Unmanaged operation
- Ready to deploy within minutes
- Maintenance-free networking
Reliable Enterprise Design
- Durable metal enclosure
- Silent fanless operation
- Business-class reliability
- CE, FCC and RoHS certified
|
Applications |
Benefit |
| IP Surveillance Systems |
Power and connect up to 16 IP cameras |
| Wi-Fi Access Points |
Reliable PoE for enterprise wireless deployments |
| VoIP Phone Systems |
Simplified installation with single-cable connectivity |
| Office Networks |
High-performance Gigabit switching |
| Schools & Universities |
Centralized network connectivity |
| Retail & Hospitality |
Reliable networking with fiber backbone support |
Why Choose Dual SFP Fiber Uplinks?
Unlike standard Ethernet-only switches, the USCX1500P-16T2S includes >two dedicated Gigabit SFP fiber ports, allowing long-distance uplink connections without sacrificing valuable RJ45 ports.
Benefits include:
- Extended network distances over fiber
- Electromagnetic interference immunity
- Faster backbone connectivity
- Improved network scalability
- Easy integration with existing fiber infrastructure
Datasheet
| Technical Specifications |
| Model |
USCX1500P-16T2S |
| Switch Type |
Unmanaged PoE+ |
| Downlink Ports |
16 × 10/100/1000Base-T RJ45 |
| Uplink Ports |
2 × 1000Base-X SFP |
| PoE Standard |
IEEE 802.3af / IEEE 802.3at |
| Installation |
Plug & Play |
| Housing |
Industrial Metal |
| Protection Rating |
IP40 |
| Cooling |
Fanless |
| Mounting |
Desktop |
| Operating Temperature |
-40°C to +85°C |
| Certifications |
CE, FCC, RoHS |
